Orifice Plate Gaskets
Bioprocessing gaskets

Our innovative Orifice Plate line includes a complete selection in both concentric and eccentric drilled plates as well as a solid plate design. Tabbed Orifice Plates and clamps are available in 1/2” – 6”. Tabs help to acknowledge that an orifice plate is “in the line” and are engraved to indicate the hole diameter. A major safety consideration! Orifice Plates can advance your system’s performance, adjust flow rates, balance backflow and equalize backpressure during SIP procedures. Achievable benefits while maintaining sanitary conditions.

Download the product sheet Orifice Plate Gaskets

  • Flow restriction
  • Reduction of Pressure
  • Offered in a concentric or eccentric self draining configuration
  • Sizes available: mini to 6”
  • Most standard drilled bore sizes available
  • Available in FKM Fluoroelastomer, Platinum Silicone, EPDM, Buna, PTFE and Tuf-Steel®
  • Flow reducer
  • Balance backpressure
  • Available with or without tab
  • Engraved tabs
  • Standard 20RA or better
  • Electropolish finish available 15RA or better
  • Prevents dead legs
  • Maintains flow while assuring self drainage thereby eliminating the potential for soil retention
  • U.S. Pharmacopeia Class VI Certification
  • Animal Derived Ingredient Free

FAQ

Orifice Plate Gaskets

Hermetically isolate the process fluid from the pressure sensor to protect it from contamination/overpressure.

PTFE or silicone depending on process chemistry and temperature constraints.
